Weight: 95 g
Display: No
Accuracy: ± 1 %
Impedance: 900 Ω
Weight Note: 95 g (3.4 oz) with cable
Cable Length: 3.3 ft
Accuracy Note: ± 1% of reading or ± 1ºC whichever is greater
Field of view: 2:1
Output Signal: Current
Repeatability: ± 0.5%
Response Time: 240 ms
Sensor Voltage: 6 Vdc
Supply Voltage: 24 to 28 Vdc
Emissivity Note: 0.2 to 1.0 via 4 to 20 mA input
Emissivity, Max: 1
Emissivity, Min: 0.2
Housing Material: Stainless Steel
Cable Length Note: 1 m (3.3') (included) longer lengths available to order
Enclosure Ratings: IP65
Temperature Range: MT-Medium
Repeatability Note: ± 0.5% of reading or ± 0.5ºC whichever is greater
Response Time Note: 240 mS (90% response)
Sensing head Mounting: 16 mm
Relative Humidity Note: 95% max non-condensing
Relative Humidity, Max: 0.95
Spectral Response, Max: 14 μm
Spectral Response, Min: 8 μm
Process Temperature, Max: 250 °C
Process Temperature, Min: 0 °C
Operating Temperature, Max: 70 °C
Operating Temperature, Min: 0 °C
