Width: 26 mm
Height: 111 mm
Length: 89 mm
Memory: 174,762 Readings
Weight: 341 g
Software: Windows XP SP3 / Vista / 7 and 8 (32 and 64 - bit)
Approvals: CE
Baud Rate: 115200
Materials: Aluminum
Resolution: Pressure : 0.002 psi, Humidity : 0.1% RH, Temperature : 0.1°C, Acceleration : 0.01 g
Calibration: Digital calibration through software and automatically recorded within device
Start Modes: Delayed Start, Immediate Start
Battery life: up to 170 hr
Accuracy Note: Calibration Accuracy : Humidity : ±3 %RH (±2 %RH typical at 25 °C), Pressure : ±1.0% FSR 25°C; ±0.2% typical, Temperature : ±0.5°C (0 to 50°C); Time Accuracy : ±1 min per month at 2 to 30°C
Pressure Type: Absolute
Pressure, Max: 0 psi
Sampling Rate: 1.953 msec
Time Accuracy: ±1 minute/month
Data Interface: USB
Humidity Range: 0 to 95% RH non-condensing
Data protection: Access by password
Millivolt Range: N/A
Measurement Type: Temperature, Humidity, Pressure, Shock
measurement-type: Temperature, Humidity, Pressure, Shock
Supply Power Type: Battery
Acceleration Range: ± 5 g
Frequency Response: 0 to 400 Hz
Sampling Rate Note: 1.953 ms/512 Hz 64 Hz to 5 minutes for shock, selectable in software. Temperature, pressure and humidity sampled approximately every 2 seconds at intervals shorter than 2 seconds. Otherwise, sampled at the reading rate.
Real Time Recording: Device can be used with PC to monitor and record instantaneous measurements in real-time
Calibration Accuracy: Humidity : ±3% RH, Temperature : ±0.5 °C, Pressure : ±1%, Accelerometer : ±0.2 g
Battery Size and Type: Alkaline 9V
Number of Measurements: 6
Process Connection Size: 1/4 in
Process Connection Type: N/A
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
Measuring Temperature Range, Max: 60 °C
Measuring Temperature Range, Min: -20 °C
