Width: 3.5 in
Height: 0.95 in
Length: 3 in
Weight: 4.9 oz
Display: LCD
Software: Windows XP SP3/Vista/7 and 8 (32 and 64-bit)
Baud Rate: 250000
Materials: Plastic
Alarm Note: User configurable audible, on-screen, email and text (SMS) alarms, Alarm Delay: A cumulative alarm delay may be set in which the device will activate the alarm (via LED) only when the device has recorded a user specified time duration of data, Audible Alarm Functionality: 1 beep per second for reading alarm above/below threshold
Input Type: Internal
Calibration: Digital Calibration through Software
Data Format: atm, °C, dew point, °F, inHg, K, kPa, m, mbar, mg/mL, mmHg, MPa, Pa, PSI, °R, %RH, Torr
Form factor: Wall Mount
Samples,Max: 10752 Samples, Interval Selectable 1 Sec to 24 hrs
Start Modes: At set date and time, Button Push, Immediate Start, Next Interval
Battery life: 5 yr, typical with reading interval of 1 min
Memory Modes: Yes
RF Frequency: 2.45 GHz
Configuration: Omega Data Logging Software, Windows PC
Pressure, Max: 1300 mBar
Pressure, Min: 250 mBar
RH Resolution: 0.1%, 12 bit
Time Accuracy: ± 1 minute/month
Band Frequency: 2.405 to 2.475 GHz
Data Interface: Wireless, USB
Calibration Date: Automated
Measurement Type: Pressure, Relative Humidity, Temperature
LED Functionality: Green LED blinks every 5 seconds to indicate unit is logging, Blue LED blinks every 15 seconds to indicate unit is in wireless mode, Red LED blinks every 1 second to indicate alarm condition
RF Frequency Note: 2.45GHz IEEE 802.15.4 ultra-low power wireless transceiver with fully bi-directional communication
Relative Humidity: 0 to 95% RH non-condensing
Supply Power Type: Battery
Current Resolution: Temperature: 0.01°C, Resistance: 0.001 Ω
Band Frequency Note: ISM band 2.405 to 2.48 GHz (channels 11 through 25) @ 250 kbps data rate
Data Interface Note: USB to mini USB, 250,000 baud for standalone operation or OM-CP-RFC1000- EXT required for wireless operation
Calibration Accuracy: Temperature: ± 0.5°C for 0 to 50°C, Pressure: ± 10 mbar, Relative Humidity: ± 3% RH
RH Measurement Range: 0 to 95% RH
Additional Features 1: Field Upgradeable
Battery Size and Type: Li-ion, 9V
Resistance Resolution: 0.001 Ω
Number of Measurements: 3
Temperature Resolution: 0.01 °C
Operating Temperature Note: -20 to 60°C, 0.002 to 100 psi
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
Temperature Measurement, Max: 60 °C
Temperature Measurement, Min: -20 °C
