Width: 56 mm
Height: 16 mm
Length: 36 mm
Memory: 500000
Weight: 425 g
Stop Modes: Adjustable Delay Stop, Manual Through Software
Wire Gauge: 24 AWG
Alarm Delay: Programmable time delay
Form factor: Benchtop
Memory Note: 500,000 readings
Start Modes: Adjustable Delay Start, Immediate Start, Push-button
Battery life: up to 10 yr
Cable Length: 762 mm
Memory Modes: Yes
Probe Length: 153 mm
Sampling Rate: 1 Hz (1 update/second)
Time Accuracy: ± 1 minute/month
Data Interface: USB
LED Indicators: Green LED Blinks: 10 second rate to indicate logging 15 second rate to indicate delay start mode ;Red LED Blinks: 10 second rate to indicate low battery and/or full memory 1 second rate to indicate an alarm condition
Probe Diameter: 3.2 mm
Waterbox Depth: 27 mm
Waterbox Width: 73 mm
Waterbox Height: 87 mm
Measurement Type: Temperature
Supply Power Type: Battery
Sampling Rate Note: 1 reading every second to 1 every 24 hours.
Data Interface Note: USB (interface cable required); 115,200 baud
Real Time Recording: The device may be used with PC to monitor and record data in real-time
Temperature Accuracy: ± 0.1 °C
Additional Features 1: Waterproof NEMA 4 (IP65) Enclosure
Battery Size and Type: 3.6V Li-ion
Electrical Connection: Miniature Female Thermocouple Connector Non-Window
Number of Measurements: 2
Software Compatibility: Windows® XP/VISTA/7 and 8 (32- and 64-bit)
Remote Channel Accuracy: ± 2.0°C
Temperature Sensor Type: Thermocouple
Process Temperature, Max: 80 °C
Process Temperature, Min: -40 °C
Operating Temperature, Max: 80 °C
Operating Temperature, Min: -20 °C
Remote Channel Temperature: -270 to 1070 °C
Temperature Sensor Type Note: Thermocouple
Thermocouple Resistance, Max: 100 Ω
Internal Channel Calibrated Accuracy: ± 0.25°C
