Height: 5.5 in
Length: 5.2 in
Memory: Non - Volatile
Display: lcd
Accuracy: ± 0.2 %
Materials: FKM, Fluoroelastomer, PC, ABS, Polyvinylidene Fluoride
Beam Width: 3 in
Compliance: CE
Resolution: 0.039 in
Configuration: Push button
Output Signal: Current
Loop Resistance: 500 Ω @ 24 Vdc
Number of Wires: 2
Number of Digits: 6
Signal fail-safe: 4 mA, 20 mA, 21 mA, 22 mA or hold last
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP65, NEMA Type 4X
Media Compatibility: Alkaline solutions, Dilute Acids, Hydraulic Oil, Light Oil, Oil, Solvents, Water, Water-based fluids
measuring-range-max: 18 ft
Measuring Range, Max: 18 ft
Measuring Range, Min: 8 ft
Display Measuring Units: cm, in, %
Operating Pressure, Max: 30 psi
Process Connection Size: 2 in
Process Connection Type: NPT Male
Process Temperature, Max: 60 °C
Process Temperature, Min: -20 °C
Temperature Compensation: Automatic
Operating Temperature, Max: 71 °C
Operating Temperature, Min: -40 °C
