Approvals: CE, RoHS, UKCA, UL cULus
Insulation: PVC
Wire Gauge: 20 AWG
Switch Note: Approximately 1/2 the distance from the end of stem to mounting or halfway point of float travel
Switch Type: SPST
Cable Length: 24 in
Switch Rating: 1 A @ 60 or 120 Vac/Vdc
Specific Gravity: 0.7
Switch Operation: Selectable Normally Open or Normally Closed
Enclosure Ratings: IP68, NEMA Type 6
Materials, Wetted: 316 Stainless Steel, Brass, Buna-N (NBR)
Media Compatibility: Oil, Solvents, Water
Operating Pressure, Max: 225 psi
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature Note: Water: -40 to 82°C, Oil: -40 to 110°C
Operating Temperature, Max: 110 °C
Operating Temperature, Min: -40 °C
