Weight: 2.7 kg
Approvals: RoHS
Materials: Aluminum, 316 Stainless Steel
Insulation: PVC
Time Delay: 0.1 to 5 sec
Sensitivity: 0.5 to 50 kΩ
Switch Type: SPDT NO/NC, Selectable
Probe Length: 48 in
Switch Rating: 1 A @ 60 or 120 Vac/Vdc
Supply Voltage: 24 Vdc
Rod Length, Max: 48 in
Electrodes Output: 12V to 100 Hz
Enclosure Ratings: IP66, NEMA Type 4
Materials, Wetted: ETFE
Power Consumption: 2 VA
Supply Power Note: 24 Vdc (± 10%)
Supply Power Type: DC
Media Compatibility: Oil, Solvents, Water
Electrical Connection: 1/2 in NPT female Conduit with Screw Terminal block
Operating Pressure, Max: 290 psi
Process Connection Size: 3/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 120 °C
Operating Temperature, Min: -10 °C
Material Construction Option: ETFE
