Accuracy: ± 0.04 inH2O
Approvals: CE
Vibration: 400 Hz
Insulation: Shield and PP Jacket
Switch Type: SPST
Cable Length: 1000 ft
Probe Length: 4.5 in
Repeatability: ± 0.02 inH2O
Switch Rating: 1 A @ 60 VA
Supply Voltage: 12 to 28 Vdc
Number of Wires: 5
Enclosure Ratings: IP68, NEMA Type 6
Materials, Wetted: PPS
Power Consumption: 25 mA
Supply Power Type: DC
Media Compatibility: Oil, Solvents, Water
Operating Pressure Note: 150 psi @ 25°C (76°F), derated @ 1.667 psi per °C above 25°C (76°F)
Operating Pressure, Max: 150 psi
Process Connection Size: 3/4 in
Process Connection Type: BSPP Male
Operating Temperature, Max: 80 °C
Operating Temperature, Min: -40 °C
