Shock: 1000 g, 11 ms
Bandwidth: 300 Hz (-3 dB)
Vibration: 5 to 20 Hz, 0.5" p-p; 20 to 2000 Hz, 4.2 g p-p
Resolution: 0.025% of FS
Output Detail: 0 to 10V output with 12 to 30V input, 35 mA max
Housing Length: 88.9 mm
Supply Voltage: 12 to 30 Vdc
Mounting Torque: 0.41 Kgf/cm
Housing Diameter: 19 mm
Housing Material: Stainless Steel
Measurement, Max: 6 mm
Measurement, Min: 0 mm
Electrical Output: 0 to 10 V
Enclosure Ratings: IP67
Relative Humidity: 95% RH, non-condensing
Additional Features 1: Spring loaded
Temperature Coefficient: 0.015% of FS/°C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -20 °C
