Speed: 38,400 bps to 600 bps
Functions: Repeater for ASCII code
Digit Size: 4 in
Input Type: N/A
Data Format: 8 data bits: even parity: 1 stop bit, 8 data bits:no parity:1 stop bit, 8 data bits: no parity: 2 stop bits, 8 data bits: odd parity: 1 stop bit
Form factor: Panel mount, Wall Mount, Suspended
Applications: Assembly Line, Control Panel, Laboratories and Scientific
Display Type: 6 Digit LED
Configuration: Front Keypad (Optional remote control)
Display Color: Red
Display Range: -199999 to 999999
Data Interface: RS485
Decimal Points: Configurable
Supply Voltage: 85 to 265 Vac
Number of Inputs: 1
Display Type Note: Single LED Display, Red Display
Enclosure Ratings: IP65, NEMA Type 4
Power Consumption: N/A
Supply Power Note: 85 to 265 Vac; 120 to 370 Vdc (isolated 2500 Vac)
Supply Power Type: AC
Data Interface Note: Address: 1 to 31
Additional Features 1: Modular Outputs
Electrical Connection: Screw Terminal
Sensor/Transmitter Power: 5 Vdc, 9 Vdc, 15 Vdc, 18 Vdc (max. 70 mA)
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -20 °C
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
