Shock: Drop Testing: 1 m (3') onto hard surface;Topple Testing: 10 times each end onto hard surface
Bandwidth: 500 Hz (-3 dB)
Vibration: 10 to 50 Hz: 1 to 10 g rms linear amplitude;50 Hz to 1 kHz: 10 g rms amplitude
Cable Type: PFA
Cable Length: 2 m
Core Material: Nickel-iron
Output Ripple: 0.0002
Housing Length: 135 mm
Supply Current: 25 mA
Supply Voltage: 10 to 30 Vdc
Linearity Error: <0.2% FSO
Housing Diameter: 61.3 mm
Housing Material: 300 Series Stainless Steel
Measurement, Max: 20 mm
Measurement, Min: 0 mm
Electrical Output: 0 to 10 V
Enclosure Ratings: IP67
Additional Features 1: Wet and Corrsoive Enviornment
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -20 °C
Operating Temperature, Max: 65 °C
Operating Temperature, Min: 0 °C
