Input Voltage Range: 30 Vdc maximum
Measuring Range
Not for condensing humidity conditions.
Temperature:
Standard: -30 to 75°C (-22 to 167°F)
Special: -20 to 75°C (-4 to 167°F)
Relative Humidity: 0 to 100%
Accuracy
Temperature: ±0.6°C from 0 to 50°C (32 to 122°F); ±1.25°C from -30 to 0°C (-22 to 32°F) and 50 to 75°C (122 to 167°F)
Relative Humidity: ±2.5% from 20 to 80% RH; ±3.5% from 5 to 20% and 80 to 95% RH; ±4% from 0 to 5% and 95 to 100% RH
Output: 0~10 Vdc for 0 to 100% RH and -30 to 75°C (-22 to 167°F)
Relative Humidity Temperature Compensation: -30 to 75°C (-22 to 167°F)
Temperature Response Time: 5 seconds minimum, 30 seconds maximum
Relative Humidity Response Time: 8 second typical
Repeatability: ±0.1% RH, ±0.2°C (0.4°F)
Sample Rate: 1 sample every 4 seconds
Housing: Gray polycarbonate, NEMA rated up to 13 (IP54)
Connections: Liquid-tight nylon with neoprene gland, for 2.50 to 8.00 mm (0.09 to 0.315") diameter cable; internal 6 position terminal block accepts 14 to 22 gauge wire
Weight: 352 g (12.4 oz)
Display
Indicators: Two 4 digit backlit LCD
Display Rate: 1 reading per second
Display Resolution:
Relative Humidity: 0.1% RH
Temperature: 0.1°C (0.1°F)
Comes complete with operator’s manual
