RH Accuracy: ±1% RH
RH Measurement Range: 5 to 95%
Time Constant: <15 sec, air flow dependent (for 66.6% response)
Temp Accuracy: ±0.5°C (1.0°F)
Temp Measurement Range: -20 to 120°C (-4 to 248°F)
Serial Output: RS232C (bi-directional) to DTE device, 19.2 kilo baud, 8 bits data, 1 stop bit, no parity
Power Requirements: 18 to 30 Vdc unregulated, 50 mA max
Sensor Dimensions:
Probe: 19 Dia. x 203 mm (¾ x 8")
Cable Length: 1.8 m (6'')
Filter: Sinter stainless steel (removable and cleanable)
Probe Material: Stainless steel
Fitting: Adjustable ¾ NPT
Weight: 0.9 kg (2 lb)
Electrical Analog Outputs: 0 to 10 Vdc (x3) @ 10 mA max
High pressure: 0~ 200 psia (±0.75psi)
Standard scaling of analog ouput:
Output 1 (RH): 0 to 100%
Output 2 (Air temp): -20 to 120°C (-4 to 248°F)
Output 3 (Dew point or pressure): 0~ 200 psia
