Width: 2 in
Height: 1.6 in
Length: 4.3 in
Accuracy: ± 1 %
K-Factor: 291 pulses/gal
Approvals: CE
Display Type: LCD
Output Signal: Current
Repeatability: ±0.1%
Certifications: NIST Traceable Calibration
Calibration Note: Gallons Per Minute (Gallons Default)
Electrical Output: 37 to 370 Hz
Enclosure Ratings: IP65, NEMA Type 4
Materials, Wetted: 316 Stainless Steel, Alumina Ceramic, Aluminum, PVDF, Tungsten Carbide
Media Compatibility: Liquids
Battery Size and Type: Alkaline AAA
Operating Pressure, Max: 1500 psi
Process Connection Size: 1 1/2 in
Process Connection Type: NPT Female
Volumetric Flow Rate, Max: 20 GPM
Volumetric Flow Rate, Min: 5 GPM
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -18 °C
