Width: 0.7 in
Height: 1.3 in
Length: 0.3 in
Weight: 1.1 oz
Materials: Plastic
Hysteresis: 3.3 ft/s fixed
Wire Gauge: 26 AWG
Switch Type: SPST NO Reed
Cable Length: 20 in
Switch Rating: 170 mA
Cable Diameter: 0.2 in
Switch Type Note: NO (Normally Open): Contact closed with air flow
Enclosure Ratings: IP20, NEMA Type 1
Contact Resistance: 370 mΩ
Switch Rating Note: 10 W, 60 Vdc@ 170 mA DC
Media Compatibility: Air
Mounting Orientation: Air-flow monitor opening perpendicular to air flow
Linear Flow Rate, Min: 8.2 ft/s
Process Temperature, Max: 80 °C
Process Temperature, Min: -20 °C
Operating Temperature, Max: 50 °C
Operating Temperature, Min: -20 °C
Material Construction Option: 120 x 120 mm Finger Guard
