Width: 2.45 in
Height: 2.63 in
Length: 3.7 in
Accuracy: ± 0.02 %
Materials: Polypropylene, Stainless Steel, Epoxy, Nylon, PVC
Switch Type: SPDT NO/NC, Selectable
Cable Length: 10 m
Display Type: None
Output Detail: Load Driving Capacity: 1150 Ω max
Output Signal: Relay
Response Time: 2 sec
Switch Rating: 5 A @ 120/240 Vac
Supply Voltage: 12 to 35 Vdc
Viscosity Range: 0 to 5 cPs
Materials, Wetted: Acetal Copolymer, Buna-N (NBR), Glass, PEEK, Polycarbonate, Polypropylene, Stainless Steel
Type of Operation: Flow Switch
Response Time Note: 2 s to 90% (step change in flow rate)
Media Compatibility: Liquids
Repeatability Error: 0.005
Electrical Connection: Cable
Operating Pressure, Max: 150 psi
Process Connection Size: 1/2 in
Process Connection Type: NPT Female
Volumetric Flow Rate, Max: 18.9 l/min
Volumetric Flow Rate, Min: 1.9 l/min
Material Construction Option: Visual Indicator
