Width: 2.1 in
Height: 2.2 in
Length: 4.1 in
Accuracy: ± 0.01 %
K-Factor: 375 to 460 pulses/gallon
Approvals: RoHS, CE
Cable Length: 18 ft
Supply Current: 2 mA
Supply Voltage: 6 to 24 Vdc
Viscosity Range: 1 cSt
Electrical Output: Amplified Square Pulse, NPN Open Collector
Materials, Wetted: EPDM, Nickel Tungsten Carbide, Polypropylene, Ruby, TFE Acrylic
Supply Power Note: 6 to 24 Vdc @ 2 mA
Pressure Drop Note: Maximum Pressure Drop: 15 psi on size 2 units 20 psi on all other sizes
Pressure Drop, Max: 20 psi
Media Compatibility: Oil, Solvents, Water
Operating Pressure, Max: 150 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 3/4 in
Process Connection Type: NPT Female
Process Temperature, Max: 70 °C
Volumetric Flow Rate, Max: 20 GPM
Volumetric Flow Rate, Min: 0.2 GPM
Material Construction Option: Polypropylene Body, Visual Indication
