Weight: 0 kg
Accuracy: ± 1 %
K-Factor: 15 Hz/fps
Approvals: CE
Cable Type: Twisted Pair with Foil Shield with Drain
Cable Length: 25 ft
Pressure Type: Gauge
Velocity, Max: 20 ft/s
Velocity, Min: 0.3 ft/s
Pipe Size, Max: 4 in
Pipe Size, Min: 0.5 in
Supply Current: 1.5 mA max
Supply Voltage: 3.3 to 24 Vdc
Linearity Error: ±1%
Cable Length Note: 7.6 m (25') [300 m (1000') maximum]
Electrical Output: Open Collector, Sinking
Materials, Wetted: FKM, Polypropylene, Titanium
Supply Power Note: 3.3 to 24 Vdc <1.5 mA @ 3.3V to 6 Vdc, <20 mA @ 6V to 24 Vdc
Pressure Drop Note: Very Low Pressure Drop
Media Compatibility: Liquids
Repeatability Error: ±0.5%
Mounting Orientation: Mounting Kit
Operating Pressure Note: PP sensor housing: 180 psi @ 20°C (68°F), 25 psi @ 85°C (185°F)
Operating Pressure, Max: 180 psi
Operating Pressure, Min: 0 psi
Process Temperature, Max: 85 °C
Process Temperature, Min: 0 °C
Material Construction Option: Polypropylene housing, Titanium shaft
material-construction-option: Polypropylene housing, Titanium shaft
