Accuracy: ± 1 %
Approvals: CE
Alarm Types: 2
Display Type: LCD
Output Detail: Linear 0 to 5 Vdc (3000 Ω minimum load impedance); linear 4 to 20 mA (500 Ω maximum loop resistance). Maximum noise 20 mV peak to peak (for 0 to 5 Vdc output); Flow Pulse Output: 3.3 Vdc
Pressure Type: Gauge
Response Time: 1 s
Approvals Note: EMC Compliance with 89/336/EEC as amended. Emission Standard: EN 55011:1991, Group 1, Class A Immunity Standard: EN 55082-1:1992
Data Interface: RS232
Viscosity Note: 1 cSt (water) can be used for liquids up to 50 cSt with field calibration (max flow range may be affected
Display Type Note: Optional local 2 x 16 characters LCD with adjustable backlight (2 lines of text),Optional 4 pushbutton key pad
Electrical Output: 4 to 20 mA, 0 to 5 Vdc
Enclosure Ratings: IP67, NEMA Type 4X
Materials, Wetted: EPDM, Nickle Tungston Carbide, Polypropylene, Sapphire
Supply Power Note: 11 to 26 Vdc, 100 mV maximum peak to peak output noise, Consumption: +12 Vdc (150 mA maximum); +24 Vdc (100 mA maximum); circuit board have built-in polarity reversal protection, 300 mA resettable fuse provide power input protection.
Pressure Drop Note: Maximum Pressure Drop: @ 15 psi for sized units @ 20 psi all other sizes
Pressure Drop, Max: 1 psi
Response Time Note: Approx 1 sec (above 10% of full scale flow), approx 2 seconds (below 10% of full scale flow)
Digital Output Note: UCE 40 Vdc, ICE 150 mA
Repeatability Error: ±0.25%
Temperature Accuracy: ± 0.5 °C
Operating Pressure, Max: 150 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 3/8 in
Process Connection Type: NPT Female
Process Temperature, Max: 60 °C
Process Temperature, Min: 0 °C
Volumetric Flow Rate, Max: 5 GPM
Volumetric Flow Rate, Min: 0.5 GPM
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -10 °C
Material Construction Option: Polypropylene Body
