Width: 3.2 in
Height: 1.42 in
Length: 3.96 in
Weight: 9.6 kg
Mounting: Horizontal Surface ±30°
Cable Length: 25 m
Display Type: None
Output Detail: Open collector NPN transistor, 10 mA maximum sink
Linearity Error: ±1%
Viscosity Range: 0 to 20 cPs
Electrical Output: 10_mA
Materials, Wetted: FKM, PEEK, Polyphenylene Sulfide
Pressure Drop, Max: 25 psi
Media Compatibility: Liquids
Repeatability Error: 0.005
Operating Pressure, Max: 80 psi
Process Connection Size: 7/1-R 1/4 in
Process Connection Type: International Organization for Standardization (ISO)
Volumetric Flow Rate, Max: 2.6 l/min
Volumetric Flow Rate, Min: 0.11 l/min
Operating Temperature, Max: 80 °C
Operating Temperature, Min: 0 °C
