Weight: 0 lb
Accuracy: ± 0.7 %
K-Factor: 15000 pulses/gal
Materials: ABS
Resolution: 0.25 ml/pulse
Cable Length: 10 m
Conductivity: > 20 µS/cm
Accuracy Note: ± 0.7 % of reading ± 0.3 % of range
Output Detail: 0.5 to 10 V
Output Signal: Current
Repeatability: ± 1%
Response Time: < 100 ms
Supply Voltage: 12 to 24 Vdc
Flow Indication: LED Green
Enclosure Ratings: IP65
Materials, Wetted: EPDM, PVDF, Stainless Steel
Number of Outputs: 1
Power Consumption: max 3.6 W
Supply Power Note: 12 to 24 Vdc(± 10 %)
Supply Power Type: DC
Media Compatibility: Acid Solutions, Conductive Liquids, Saltwater
Flow Indication Note: LED Green, Flow proportional flashing
Electrical Connection: M12 4 pin Female
Operating Pressure, Max: 145 psi
Process Connection Size: 1/2 in
Process Connection Type: BSPP Male
Process Temperature, Max: 140 °F
Process Temperature, Min: 14 °F
Storage Temperature, Max: 140 °F
Storage Temperature, Min: 5 °F
Volumetric Flow Rate, Max: 1.32 GPM
Volumetric Flow Rate, Min: 0.066 GPM
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 41 °F
Material Construction Option: Stainless Steel
material-construction-option: Stainless Steel
