Weight: 0 lb
Accuracy: ± 1 %
K-Factor: 1892 pulses/gal
Materials: PVDF
Cable Length: 6 m
Conductivity: > 20 µS/cm
Accuracy Note: ± 1%, ± 0.005 GPM of reading across
Output Detail: Optocoupled current sinking or current sourcing pulse output; 30 Vdc, 5 mA max, 4 to 20 mA current loop; 7 Vdc plus load voltage drop min; 50 Vdc max
Output Signal: Current
Pipe Size, Max: 0.5 in
Supply Voltage: 10 to 15 Vdc
Enclosure Ratings: IP66, NEMA Type 4X
Materials, Wetted: PVDF
Number of Outputs: 1
Supply Power Note: 10 to 15 Vdc, 150 mA (linear power supply recommended)
Supply Power Type: DC
Media Compatibility: Acid Solutions, Conductive Liquids, Saltwater
Electrical Connection: 8-pin mini DIN
Operating Pressure, Max: 150 psi
Process Connection Note: Fittings with two NPT threaded adaptors (included)
Process Connection Size: 1/2 in
Process Connection Type: NPT Male
Process Temperature, Max: 93 °C
Process Temperature, Min: 0 °C
Volumetric Flow Rate, Max: 20 GPM
Volumetric Flow Rate, Min: 0.2 GPM
Operating Temperature, Max: 54 °C
Operating Temperature, Min: -18 °C
