Accuracy: ± 1.5 %
Materials: PEEK, Aluminum
Conductivity: 50 µS/cm
Current, Max: 26_ma_approx
Accuracy Note: ± 1.5% of reading ± 0.3% range
Output Detail: Amplified Square Wave
Output Signal: Current
Repeatability: ± 1%
Response Time: < 500 ms
Supply Voltage: 24 Vdc
Flange Diameter: 0.39 in
Flow Indication: LED Green
Load Resistance: 250 Ω
Sensor Diameter: 0.25 in
Enclosure Ratings: IP65, NEMA Type 4X
Materials, Wetted: EPDM, Stainless Steel
Number of Outputs: 1
Power Consumption: 150 mA
Supply Power Note: 24 Vdc ± 10%
Supply Power Type: DC
Media Compatibility: Acid Solutions, Conductive Liquids, Saltwater
Flow Indication Note: flow proportional blinking
Electrical Connection: M12 4 pin Female
Output Pulse Rate Note: Square wave signal NPN, internal pull-up resistor 2 kΩ pulse duty ratio 50:50
Operating Pressure, Max: 232 psi
Process Connection Size: 1/2 in
Process Connection Type: BSPP Male
Short-Circuit Protected: < 30 V
Process Temperature, Max: 90 °C
Process Temperature, Min: 0 °C
Volumetric Flow Rate, Max: 7.93 GPM
Volumetric Flow Rate, Min: 0.13 GPM
Operating Temperature, Max: 70 °C
Operating Temperature, Min: 5 °C
Short-Circuit Protected Note: Measures short-circuit proof (up to 30V) and polarity protection (up to -30V)
