Weight: 1.7 lb
Accuracy: ± 0.5 %
K-Factor: 0.1 to 1000 pulses/gal
Materials: Consult factory
Conductivity: > 20 µS/cm
Display Type: LCD
Accuracy Note: ± 0.5% from 5 to 100% Qs, ± 1% from 1 to 5% Qs
Output Detail: 4 to 20 mA with galvanic isolation
Output Signal: Current
Velocity, Max: 32.81 ft/s
Velocity, Min: 0.328 ft/s
Data Interface: RS485
Pipe Size, Max: 12 in
Pipe Size, Min: 12 in
Supply Voltage: 24 Vdc
Enclosure Ratings: IP67
Materials, Wetted: Hastelloy, PTFE
Number of Outputs: 1
Power Consumption: 15 VA
Relative Humidity: 0.7
Supply Power Note: 24 Vdc, 115/230 Vac switchable (optional)
Supply Power Type: DC
Media Compatibility: Acid Solutions, Conductive Liquids, Saltwater
Output Pulse Rate Note: 0 to 1000 Hz with galvanic isolatior
Output Pulse Rate, Max: 1000 Hz
Operating Pressure, Max: 145 psi
Process Connection Size: 1 in
Process Connection Type: Tri-Clamp
Process Temperature, Max: 50 °C
Process Temperature, Min: 0 °C
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -10 °C
Volumetric Flow Rate, Max: 61 GPM
Volumetric Flow Rate, Min: 6.1 GPM
Operating Temperature, Max: 55 °C
Operating Temperature, Min: -5 °C
