Weight: 40 lb
weight: 40 lb
Accuracy: ± 0.75 %
Approvals: CE
Materials: Cast Iron, Aluminum
Cable Length: 20 ft
Conductivity: > 20 µS/cm
Display Note: 128 x 64 dot-matrix LCD
Display Type: LCD
Output Detail: 4 to 20 mA
Output Signal: Current
Velocity, Max: 10 m/s
Battery Backup: 9 V Alkaline Battery
Pipe Size, Max: 3 in
Remote Display: Yes
Supply Voltage: 86 to 264 Vac / 60 Hz
supply-voltage: 86 to 264 Vac / 60 Hz
Flange Diameter: 2.6 in
Low Flow Cutoff: 0.50 %
Pulse Rate Note: User-scalable from 0.1 to 99,999.9 volume units/pulse. Pulse width is one-half of pulse period with minimum pulse width of 2.5 ms, 200 pulses/sec max. For battery option meters, pulse width varies with frequency, 150 pulses/sec max
Number of Digits: 8
Enclosure Ratings: IP68, NEMA 6P
Materials, Wetted: 316 Stainless Steel, EPDM, Noryl
Number of Outputs: 1
Supply Power Note: 86-264Vac, 60Hz, 0.12A
Supply Power Type: AC
Media Compatibility: Acid Solutions, Conductive Liquids, Saltwater
Empty Pipe Detection: Hardware/software, conductivity-based
Remote Display Cable: 20 '
Output Pulse Rate, Max: 200 pulses/sec
Operating Pressure, Max: 150 psi
Process Connection Size: 3 in
Process Connection Type: ANSI Flange
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -40 °C
Volumetric Flow Rate, Max: 723 GPM
Volumetric Flow Rate, Min: 3.62 GPM
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -12 °C
Material Construction Option: N/A
