Weight: 30 lb
weight: 30 lb
Accuracy: ± 1 %
Approvals: CE
Materials: Steel, Epoxy, Aluminum
Cable Length: 20 ft
Conductivity: > 20 µS/cm
Display Note: 128 x 64 dot-matrix LCD
Display Type: LCD
Output Detail: Current Sinking pulse
Output Signal: DC Pulse
Velocity, Max: 10 m/s
Battery Backup: 7.2 V D size Lithium Battery
Pipe Size, Max: 3 in
Supply Voltage: 9 to 36 Vdc / 60 Hz
Flange Diameter: 3.12 in
Low Flow Cutoff: 0.50 %
Pulse Rate Note: User-scalable from 0.1 to 99,999.9 volume units/pulse. Pulse width is one-half of pulse period with minimum pulse width of 2.5 ms, 200 pulses/sec max. For battery option meters, pulse width varies with frequency, 150 pulses/sec max
Number of Digits: 8
Enclosure Ratings: IP68, NEMA 6P
Materials, Wetted: 316 Stainless Steel, EPDM, Noryl
Number of Outputs: 1
Supply Power Note: 9-36 Vdc @ 250 mA max, 30 mA average
Supply Power Type: DC
Media Compatibility: Acid Solutions, Conductive Liquids, Saltwater
Empty Pipe Detection: Hardware/software, conductivity-based
Battery Size and Type: Li-ion, 7.2V
Output Pulse Rate, Max: 200 pulses/sec
Operating Pressure, Max: 150 psi
Process Connection Size: 3 in
Process Connection Type: ANSI Flange
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -40 °C
Volumetric Flow Rate, Max: 723 GPM
Volumetric Flow Rate, Min: 3.62 GPM
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -12 °C
Material Construction Option: N/A
