Weight: 0 lb
Accuracy: ± 2 %, ± 5% with transitional flow
Approvals: CE
Isolation: Low voltage <48 Vac/Vdc from electrodes and auxiliary power
Linearity: ± 1%
Cable Length: 300 m
Conductivity: > 20 µS/cm
Accuracy Note: <± 2% of measured value in reference conditions where the fluid is water at ambient temperature, the appropriate upstream and downstream distances are observed, the sensor is inserted at the correct depth, and there is a fully developed flow profile which is in compliance to ISO 7145-1982 (BS 1042 section 2.2). 32 µA maximum error (at 25°C @ 24 Vdc)
Output Detail: 4 to 20 mA, programmable and reversible, loop
Output Signal: Current
Repeatability: ± 0.5%
Velocity, Max: 33 ft/s
Velocity, Min: 0.15 ft/s
Linearity Note: ± 1% reading + 0.01 m/s (± 1% reading + 0.033 ft/s)
Pipe Size, Max: 48 in
Pipe Size, Min: 3 in
Supply Voltage: 21.6 to 26.4 Vdc
Loop Resistance: 300 Ω
Current Sink, Max: 50 mA
Enclosure Ratings: IP68, NEMA 6P
Materials, Wetted: 316 Stainless Steel, FKM, PVC, PVDF, Rubber
Number of Outputs: 1
Supply Power Note: 4 to 20 mA (24 Vdc nominal, 21.6 to 26.4 Vdc maximum, reverse polarity and short circuit protected pipe size of DN50 to DN1200 (2 to 48")
Supply Power Type: DC
Repeatability Note: ± 0.5% of rdg @ 25°C (77°F)
Media Compatibility: Acid Solutions, Conductive Liquids, Saltwater
Pull Up Voltage, Max: 30 Vdc
Power Supply Rejection: ± 1 µA/V
Temperature Drift Note: ± 1 μA
Operating Pressure, Max: 300 psi
Process Connection Note: Standard 1 1/4" NPT Tee Adaptors, Customer Supplied
Process Connection Size: 1 1/4 in
Process Connection Type: NPT Female
Short-Circuit Protected: < 30 V
Process Temperature, Max: 85 °C
Process Temperature, Min: -15 °C
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -15 °C
Volumetric Flow Rate, Max: 0 GPM
Volumetric Flow Rate, Min: 0 GPM
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -15 °C
Short-Circuit Protected Note: <30 V @ 0 Ω pull-up for 1 hour, reverse polarity protected to -40 V for 1 hour, over-voltage protected to 40 V for 1 hour
Installation Temperature, Max: 40 °C
