Accuracy: ± 1 %
Approvals: CE
Materials: Steel, Epoxy, Santoprene, Polypropylene, Cast Iron
Cable Length: 6 m
Conductivity: > 20 µS/cm
Display Note: 128 x 64 dot-matrix LCD
Display Type: LCD
Accuracy Note: ± 1% of reading ± 0.04% of full-scale flow from low flow cutoff to maximum flow rate of 10 m/sec
Output Detail: Current sinking pulse, isolated, 36 Vdc at 10 mA max
Output Signal: DC Pulse
Velocity, Max: 10 m/s
Pipe Size, Max: 8 in
Pipe Size, Min: 8 in
Remote Display: Yes
Supply Voltage: 85 to 264 Vac / 50 Hz
Low Flow Cutoff: 0.50 %
Number of Digits: 8
Enclosure Ratings: IP68
Materials, Wetted: 316 Stainless Steel, Iron, Polypropylene
Number of Outputs: 1
Supply Power Note: DC Power : 9-36 Vdc @ 250 mA max, 30 mA average, AC Power : 85-264Vac, 50/60Hz, 0.12A
Supply Power Type: AC
Media Compatibility: Acid Solutions, Conductive Liquids, Saltwater
Empty Pipe Detection: Hardware/software, conductivity-based
Remote Display Cable: 9 '
Electrical Connection: 5 - Position Plug
Output Pulse Rate, Max: 200 pulses/sec
Operating Pressure, Max: 150 psi
Process Connection Type: ANSI Flange
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -40 °C
Volumetric Flow Rate, Max: 5140 GPM
Volumetric Flow Rate, Min: 25.7 GPM
Operating Temperature, Max: 54 °C
Operating Temperature, Min: -12 °C
