Width: 1.1 in
Height: 4.1 in
Accuracy: ± 0.8 %
Span Shift: 0.02% FS/°C/atm
Calibration: NIST 5-Point Certificate
Display Type: LCD
Accuracy Note: ± (0.8% of rdg + 0.2% FS)
Output Signal: Voltage
Repeatability: ± 0.2%
Response Time: 10 ms
Data Interface: RS232
Humidity Range: 0 to 100% RH non-condensing
Supply Current: 35 mA
Supply Voltage: 7 to 30 Vdc
Turndown Ratio: 200:1
Electrical Output: 0 to 5 V
Materials, Wetted: Aluminum, Brass, Epoxy, FKM, Glass, Gold, Silicone, Stainless Steel
Supply Power Note: 35 mA typical current draw; 100 mA available supply recommended
Pressure Drop, Min: 1 psi
Response Time Note: 10 ms typical default response time for 63.2% of a step change. A variable register allows response time to be field adjustable to a certain extent via RS232 communications. The primary trade-off for response time is signal noise
Media Compatibility: Air, Gases, Nitrogen, Oxygen
Measurable Flow Rate: 125%
Additional Features 1: Power Supply Included
Electrical Connection: 8-pin mini DIN
Operating Pressure, Max: 145 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Volumetric Flow Rate, Max: 100 SLM
Volumetric Flow Rate, Min: 0.05 SLM
Operating Temperature, Max: 50 °C
Operating Temperature, Min: -10 °C
