Height: 4.7 in
Diameter: 2.8 in
Approvals: CE
Materials: Polypropylene
Time Delay: 0.15 to 60 sec
Switch Type: SPDT NO/NC
switch-type: SPDT NO/NC
Switch Rating: 10 A
Approvals Note: CE compliance: EN 61326 EMC EN 61010‐1 Safety
Supply Voltage: 120/240 Vac
Enclosure Ratings: IP65, NEMA 4
Power Consumption: 5 W
Supply Power Note: 120/240 Vac, 50/60 Hz
Switch Rating Note: SPDT Relay, Form C, 10A, 120 Vdc or 240 Vac
Media Compatibility: Gases, Liquids
Additional Features 1: 300° swivel base
Electrical Connection: 1/2 in NPT female Conduit with Screw Terminal block
Process Connection Size: 3/4 in
Process Connection Type: NPT Female
Sensor/Transmitter Power: 13.5 Vdc @100 mA
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -40 °C
