Accuracy: Class B
Wire Length: 10 mm
Sensor Width: 2 mm
Accuracy Note: Class B per IEC60751
Lead Material: Platinum Clad Nickel Wire
Sensor Height: 0.8 mm
Sensor Length: 9 mm
Wire Diameter: 0.2 mm
Number of Wires: 2
Number of Pieces: 100
Shock Resistance: 100 g Acceleration with 8 ms Half Sine Wave
Nominal Resistance: 100 Ω
Response Time Note: Response Time Water Current (v = 0.4 m/s) t0.5 = 0.2 s, t0.9 = 0.4 s; Air Stream (v = 1 m/s) t0.5 = 3.0 s, t0.9 = 9.0 s
Response Time, Air: 3 sec @ 50%; 9 sec @ 90%
Self Heating Effect: 0.4 K/mW @ 0°C
Response Time, Water: 0.2 sec @ 50%; 0.4 sec @ 90%
Vibration Resistance: 10 to 2000 Hz sweep rate, acceleration 40g
Insulation Resistance: > 10 MΩ
Temperature Coefficient: 0.00385Ω/Ω/°C
Temperature Sensor Type: RTD
Process Temperature, Max: 500 °C
Process Temperature, Min: -70 °C
Insulation Resistance Note: >10 MΩ @ 20°C; >1 MΩ @ 500°C
