Width: 23.5 mm
Height: 109 mm
Length: 130 mm
Weight: 240 g
Mounting: DIN Rail 46277
Isolation: 3750 Vac
Stability: Load Stability: ≤0.01% of span/100 Ω
Input Type: Frequency
Fuse Rating: 400 mA SB / 250 Vac
Update Rate: 20 ms
EMC Standard: NAMUR NE 21
Output Value: Process
Warm Up Time: 1 min
Output Detail: Current Output Min. Signal Range: 5 mA Current Limit: < 23 mA Voltage Output Min. Signal Range: 250 mV Relay Output Max. Voltage: 250 VRMS Max. Current: 2 AAC Max. AC Power: 100 VA Max. Load at 24 Vdc:1 A Other Output Types: Active outputs (NPN/PNP) Other Output Types: f/f Converter Output Other Output Types: Frequency generator Of Span: = of the presently selected range
Output Signal: Current, Voltage, Relay
Response Time: Analog :< 60 ms + period;Digital Output : < 50 ms + period
Approvals Note: EMC:2014/30/EU, LVD:2014/35/EU, EAC:TR-CU 020/2011
Supply Voltage: 21.6 to 253 Vac, 19.2 to 300 Vdc
Linearity Error: < 0.1% of span
Load Resistance: Voltage Output : ≥ 500 kΩ, Current Output : ≤ 600 Ω
Input Range Note: Max. Offset: 90% of selected max. frequency;Min. Measurement Range: 0.001 Hz;Max. Frequency, with Input Filter ON: 50 Hz;Min. Period Time with Input Filter ON: 20 ms;Input Types: NAMUR acc. to DIN 19234;Input Types:Tacho;Input Types:NPN/PNP;Input Types:2-phase encoder;Input Types:TTL;Input Types:S0 acc. to DIN 43864
Number of Inputs: 1
Electrical Output: 0 to 20 mA
Enclosure Ratings: IP20
Noise Calibration: >60 dB
Power Consumption: 3.5 W, Internal - 3 W
Relative Humidity: <95% RH
Supply Power Note: Auxiliary Voltage: NAMUR Supply: 8.3 Vdc ±0.5 Vdc / 8 mA Effect of Supply Voltage: < 0.005% of span/Vdc S0 Supply: 17 Vdc/20 mA NPN/PNP Supply: 17 Vdc/20 mA Special Supply (Programmable): 5 to 17 Vdc/20 mA S0 Supply: 17 Vdc/20 mA NPN/PNP Supply: 17 Vdc/20 mA Special Supply (Programmable): 5 to 17 Vdc/20 mA
Supply Power Type: AC/DC
Optional Power Note: 0 to 999 s
Voltage Output Range: 0 to 10 V
Screw Terminal Torque: 0.5 Nm
Signal Dynamics Output: 16 bit
Temperature Coefficient: <±0.01% of span/°C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
Frequency Measurement Range: 0 to 20 kHz
Calibration Temperature, Max: 28 °C
Calibration Temperature, Min: 20 °C
