Width: 35.5 mm
Height: 80.5 mm
Length: 84.5 mm
Offset: Max Offset: 70 %
Weight: 130 g
Mounting: DIN Rail Mount
Stability: Load Stability: 0.01% of span/100 Ω
Input Type: Voltage
Update Rate: 20 ms
Display Type: LED
EMC Standard: NAMUR NE 21
Output Value: Process
Output Detail: Min. Signal Range: 5 mA Current Limit: < 23 mA Voltage Output Through Internal shunt: See manual for details Of Span: = of the presently selected range
Output Signal: Current
Response Time: 0.06 to 999 s
Approvals Note: EMC 2014/30/EU EAC: TR-CU 020/2011
Supply Voltage: 19.2 to 28.8 Vdc
Linearity Error: < 0.1% of span
Load Resistance: 230 mA Max;Current Output : 600 Ω
Input Range Note: Max. Offset: 70% of selec. max. value;Voltage input;Min. Measurement Range (Span): 10 mV;Overrange: 0 to 999% of selected measurement range;NPN, Digital Input: Pull up 24 Vdc / 6.9 mA;PNP, Digital Input: Pull down 0 Vdc/6.9 mA;Trig Level Low, NPN/PNP: < 6 Vdc;Trig Level High, NPN/PNP: > 10.5 Vdc;Pulse Length: > 30 ms
Number of Inputs: 1
Electrical Output: 0 to 20 mA
Enclosure Ratings: IP50
Noise Calibration: >60 dB
Power Consumption: 7.2 W
Power Dissipation: 2.2 W
Relative Humidity: <95% RH
Supply Power Note: Effect of Supply Voltage Change: < ±0.002% of span/%V Supply: 5 to 13 Vdc
Supply Power Type: DC
Signal Dynamics Input: 17 bit
Signal Dynamics Output: 16 bit
Temperature Coefficient: <±0.01% of span/°C
Voltage Measurement Range: -40 to 100 mV dc
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
Calibration Temperature, Max: 28 °C
Calibration Temperature, Min: 20 °C
