Width: 3.48 in
Height: 1.89 in
Length: 3.58 in
Weight: 150 g
Accuracy: ± 0.05 %
Mounting: Panel
Input Type: Strain
Form factor: 1/8 DIN
Power Wires: max. 2.5mm²
Display Note: Digits: 6; Reading: 999999/-199999; Decimal Point: Configurable; LED color: Red Digit; Height: 14mm (0.55’’)
Display Type: LED
Output Signal: N/A
Sampling Rate: 60 Hz (60 updates/second)
Step Response: 17, 20 or 63 mSec (0% to 99% of signal)
Control Output: N/A
Data Interface: RS485
Load Cell Type: 1 mV/V, 2 mV/V, 3 mV/V
Supply Voltage: 85 to 265 Vac/Vdc
supply-voltage: 85 to 265 Vac/Vdc
Impedance Input: 20 MΩ
Number of Cells: 1 to 8 load cells (at 5 Vdc) and 1 to 4 load cells (at 10 Vdc)
Number of Wires: 4, 6
External Contact: Configurable Functions
Input Range Note: 100mV, 30mV, 20mV, 15mV, 10mV, 5mV
Measurement Type: Strain
Number of Digits: 6
Number of Inputs: 1
Number of Relays: N/A
Cutout Dimensions: 1.74 x 3.63 in
Enclosure Ratings: IP65, NEMA Type 4
Power Consumption: 1.5 W 4 W
Sensor Excitation: 5 Vdc or 10 Vdc (configurable), Maximum Exc. Current: 140 mA, Maximum Vdc at Input: ± 30 Vdc
Supply Power Type: AC/DC
Thermal Stability: 50ppm/°C
Step Response Note: 17, 20 or 63 mSec (Configurable)
Data Interface Note: Module-RTU Type of bus: RS-485, up to 57.6 Kbps, Accuracy: 0.1% FS, Isolation: 1000Vdc, Terminal: plug-in screw terminal, pitch 5.08mm, Installation allowed at: Opt.1, Opt.2 and Opt.3
Input Configuration: Front Keypad
Electrical Connection: Screw Terminal
Power Consumption Note: <1.5W (meter only) and <4.0W (meter with output options)
Acquisitions per Second: 16, 50 or 60 acq./sec. (configurable)
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -20 °C
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
