Backlight: false
Menu Mode: Engineering Units: 10 units of measurement are available; psi, In. H2O (with three temp. options: 20°C, 60°F, 4°C*), Ft. H2O, mPa, mBar, kPa, kg/cm2 , Bar, inHg and mmHg. Configuration Mode: Allows for changes to default settings of gauge Allows for changes to default settings of gauge. Bar Graph: Allows for adjustment of bargraph and 4-20 (optional feature). Auto Off (Off): Allows for changes to auto off of gauge, five options: Never, 2 min., 5 min., 15 min., 30 min. Update Rate: Four options: 100 ms, 200 ms, 500 ms, 1 sec Dampening: Six options: None, average, 2, 4, 6, 8 times per 100ms. Backlite: Five options: Never, 10 sec., 30 sec., 1 min., 5 min. Field Recalibration:Allows for recalibration of zero, midscale and span (password protected)
Battery life: 1000 hr
Display Type: LCD
Accuracy Note: 0.25% Full Scale, terminal point
Pressure Type: Compound Gauge
Pressure, Max: 30 psi
Pressure, Min: -15 psi
Accuracy Class: 0.1% to 0.25%
Outer Diameter: 4.5 in
Supply Voltage: 12 to 36 Vdc
Keypad Functions: On/Off: Manually turns unit on and off (auto off options in menu) Zero/Clear: Zeros display or clears min. and max. values when displayed Min/Max (down) Stores min and max values, arrow key allows for Arrow Key: scrolling thru menu items. Menu Key: Provides access to menu options. Backlite Arrow Key: Manually turns backlite on and off (auto off options in Arrow Key: menu), arrow key allows for five menu options. (up)arrow key allows for scrolling thru menu options. Enter: Selects items in the menu.
Number of Digits: 5
Display Type Note: Type: LCD Display Digits: Five (5) Character Height: 3˝ .60˝, 41 ⁄2˝ .88˝ Backlite: Optional Bar Graph: Yes Battery Life: 3˝ >1000 hrs., 41 ⁄2˝ >3600 hrs. Agency Approvals: CE, FM* (Intrinsically Safe Class1, Div 1), CSA and CENELEC *FM is not available with the following: 41 ⁄2˝ polypropylene case, SPDT switch option(s) (XU1, U2) or Backlite (XBL) option).
Pressure Accuracy: ± 0.25 %
Supply Power Note: 12-36 Vdc, 2VA maxBattery Note:
Supply Power Type: Loop Powered
Enclosure Material: Fiber Reinforced Thermoplastic
Connection Location: Lower, Left, Right, Upper
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Storage Temperature, Max: 158 °F
Storage Temperature, Min: -4 °F
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 14 °F
