Weight: 165 g
Input Type: Themocouple, RTD, Current, Voltage
Form factor: 1/8 DIN
Display Type: Graphical OLED
Output Detail: 2A - 250VAC (resistive charge)
Sampling Rate: 4.12 Hz to 242 Hz (4.12 to 242 updates/second)
Control Output: 2 SPDT Relay
Data Interface: RS485
Supply Voltage: 24 to 230 Vac/Vdc
Input Type Note: 1 Analogue: Res.16 bit, Selecting for T/C type K, S, R, J, T, E, N, B (automatic compensation of the cold junction 0 ~ 50 °C, ± 0,2% F.S. ± 1 Digit F.S.), thermoresistances PT100, PT500, PT1000, Ni100, PTC1K, NTC10K (ß 3435K), process signals 0-10 V(54000 points), 0/4-20mA(40000 points), 0-60 mV (16000 points), Potentiometer 6 KO, 150 KO (50000 points) Customizable linear input (max 16 steps) 2 Digital: PNP inputs programmable for Run / Hold / Tare-Zero / Alarms reset/ Peaks reset/ Totalizer reset / Activate-Reset Sum / Parameters-Setpoint Lock
Number of Inputs: 1
Cutout Dimensions: 48 x 96 mm
Enclosure Ratings: IP65, NEMA Type 4
Power Consumption: 8 VA
Relative Humidity: 35 ~ 95 RH% (non condensing)
Supply Power Note: 24 ~ 230VAC/DC ±10% 50/60 Hz (galvanic isolation 2500V)
Supply Power Type: AC/DC
Thermocouple Type: J, K, T, E, R, S, B, N
Enclosure Material: Polycarbonate V0
Data Interface Note: RS485 Modbus RTU - Slave (1200 ~ 115200 Baud) galvanically isolated from Power supply/Inputs/Outputs
Quick Set-up Options: Software LABSOFTVIEW and/or Memorycard
Additional Features 1: Trend visualization
Electrical Connection: Screw Terminal
Output Configurations: 2 Analog Current
Sensor/Transmitter Power: 24 VDC - 30mA for external sensors supply (loop-powered)
Operating Temperature, Max: 45 °C
Operating Temperature, Min: 0 °C
Output Configurations Note: 1 output 0 ~ 10V (60000 points) - 1 output 0/4 ~ 20mA (60000 points) Analogue Retransmission: Process values / Setpoints
