CMRR: 100 dB at 50/60Hz, 500V RMS max CMV, input to output at 60Hz
Width: 25.4 mm
Filter: Digital Filtering: Small and large signal with user selectable time ;constants from 0 to 16 seconds
Height: 83.9 mm
Length: 86.5 mm
Memory: Non Volatile Memory Eliminates pots and Switches
Offset: Offset Control: Full input range
Parity: Odd, Even, None
Accuracy: ± 0.05 %
Software: Windows PC Software
Approvals: CE
Baud Rate: 300 to 38,400
Materials: ABS
Input Type: Voltage
Protection: Input Burnout: 250 Vac
Resolution: 0.01% (4 digits)
Zero Drift: +1 Count max (autozero)
Calibration: Autozero and autocalibration; no adjustment pots
Data Format: NRZ Asynchronous
Output Value: Process
Microcomputer: 8-bit CMOS; digital scaling, linearization and calibration
Output Signal: RS485
Serial Number: Input Burnout Protection: To 250 Vac normal mode
Data Interface: Modbus RTU, ASCII, RS485
Supply Voltage: ± 5 Vdc
Conversion Rate: 8 Conversions per Second
Leakage Current: < 2 μA
Input Range Note: +10 mV, +100 mV, +1V, +5V, +10V, +100 Vdc
Number of Inputs: 1
Relative Humidity: 0 to 95% RH (non-condensing)
Supply Power Note: Regulated +5 Vdc, 0.75 W max (DIN-150, 2.0 W max); protected against power supply reversals
Supply Power Type: DC
Excitation Voltage: 10 Vdc
Additional Features 1: Address: User Selectable Channel address; Multi-Drop Modules: Up to 247 multi-drop modules per host serial port
Electrical Connection: Screw Terminal
Temperature Coefficient: Span Temperature Coefficient: +50 ppm/°C max
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -25 °C
Voltage Measurement Range: 5 V
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -25 °C
