Input Type: Digital
Form factor: 1/16 DIN
Samples,Max: 2/sec
Display Size: 10.2 mm (0.40 in)
Display Type: 4 Digit LED
Probe Length: 51 mm
Ramp and Soak: Single Ramp & Soak
A/D Conversion: A/D Conversion: 12-bit RH and 14-bit temp Reading,Rate: 2 samples per sec max,Digital Filter: Programmable Decimal Selection: None, 0.1 for temperature and humidity
Control Action: Action: Reverse (heat) or direct (cool)
Control Output: SSR Relay, Analog Output
Data Interface: Ethernet
Supply Voltage: 20 to 36 Vdc
Measurement Type: Temperature, Humidity
Number of Inputs: 2
Display Type Note: Display: 4-digit, 9-segment LED i32, i16D, i8DV: 10.2 mm (0.40") i8: 21 mm (0.83") i8DH: 10.2 mm (0.40") and 21 mm (0.83") RED, GREEN and AMBER programmable colors for process variable, setpoint and temp units
Enclosure Ratings: IP65, NEMA Type 4X
Number of Outputs: 2
Relative Humidity: 90% RH non-condensing
Supply Power Note: Low voltage power option: 20 to 36 Vdc, 24 Vac ±10%; 12 to 36 Vdc, 24 Vac ±10% for iTH-32
Supply Power Type: DC
Data Interface Note: Ethernet: Standards compliance IEEE 802.3 10Base-T
Additional Features 1: 2 inch Probe
Probe Dimensions Note: 51 mm (2") probe for iTH with 1 m (3') cable
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
