Weight: 227 g
Accuracy: ± 0.25 %
Bezel Size: 48 mm
Input Type: Thermocouple, RTD, mA, Voltage
Form factor: 1/16 DIN
Panel Depth: 133 mm
Display Size: 7.62 mm (0.30 in)
Display Type: 4 Digit LED
Accuracy Note: ±0.25% of span, ±1 least significant digit
DIN Rail Size: 0.0625 mm
Memory Backup: Non-Volatile
Output Detail: Relay Control Output Ratings: Resistive: SPST, 3 A @ 240 Vac Inductive: 1.5 A @ 240 Vac
Control Output: NO/NC relay, 0 to 20mA
Supply Voltage: 100 to 240 Vac
Measuring Range: Thermocouple Type K: -200 to 2500°F Type J: -100 to 1600°F Type T: -350 to 750°F Type E: -100 to 1800°F Type N: -100 to 2372°F Type R: 0 to 3200°F Type S: 0 to 3200°F Type B: 75 to 3308°F Type L(J DIN): -100 to 1600°F Type C: 0 to 4208°F RTD (2 wire) Pt100 RTD (0.00385): -200 to 875°C Pt100 RTD (0.00392): -200 to 875°C RTD, 120 Ω Nickel (0.00628): -80 to 320°C RTD, Pt1000 (0.00385): -200 to 875°C Process Current 0 to 20 mA, 4 to 20 mA: 1999 to 9999 Process Voltage 0 to 10Vdc, -10 to 10 Vdc, -10 to 10 mVdc: 1999 to 9999
Panel Thickness: 6.35 mm
Number of Inputs: 1
Cutout Dimensions: 45 x 45 mm
Display Type Note: Two 4-digit, 7-segment, 7.62 mm H (0.3") LEDs
Number of Outputs: 2
Power Consumption: 5 VA
Supply Power Note: 100 to 240 Vac, nominal, 10 to 15%, 50 to 400 Hz; single phase; 132 to 240 Vdc, nominal, 10 to 20% Selectable Input: 10 thermocouple, 4 RTD, DC voltage or DC current
Supply Power Type: AC
Additional Features 1: None
Temperature Sensor Type: Thermocouple
Operating Temperature, Max: 55 °C
Operating Temperature, Min: -10 °C
