Curve Type: D
Wire Gauge: N/A
Applications: Energy Generation and Distribution
Current Type: AC
Amperage, Max: 16 A
Color Options: Black
Voltage Rating: 277 Vac
Electrical Life: 6,000 cycles on/off
Mechanical Life: >10^5 cycles
Number of Poles: 2
Enclosure Ratings: IP20
Tightening Torque: 17.7 to 22 lb-in
V/A/AWG Compliance: Top Wire Gauge=18 to 3 AWG;Bottom Wire Gauge=18 to 2 AWG
Calibration Temperature: 40 K
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -25 °C
Operating Temperature, Max: 55 °C
Operating Temperature, Min: -25 °C
