Width: 0.875 in
Height: 3.33 in
Weight: 2.2 oz
Diameter: 0.875 in
Mounting: Pipe or Panel
Materials: Anodized Aluminum,Plated Steel,Brass,Acetal,Fabric Flurocarbon
Pressure Type: Gauge
Flow Rate Note: Flow Capacity at 100 psig (6.9 bar) Supply and 20 psig (1.4 bar) Outlet: 2.5 SCFM (71 LPM)
Media Compatibility: Corrosive Gases, Corrosive Liquids
Supply Pressure, Max: 250 psi
Exhaust Capacity Note: Exhaust Capacity (5 psig Above 20 psig Setpoint): 0.1 to 0.3 SCFM (2.8 to 8.5 LPM) typical
Total Air Consumption: 3 SCFM
Process Connection Size: 1/16 in
Process Connection Type: NPT Female
Air Supply Pressure, Max: 15 psi
Air Supply Pressure, Min: 0 psi
Volumetric Flow Rate, Max: 2.5 SCFM
Total Air Consumption Note: Total Air Consumption @ Maximum Output: 3 SCFH (84.6 LPM)
Supply Pressure Sensitivity: <0.25 psi
