Measuring Range
Absolute: 100 mm
Application Range
Internal Plain: 3 -100 mm
Cylindrical Thread Internal (D2) (Pitch: 0.5 - 6mm): 3-100 mm
External Taper*: up to 80 mm
Internal Taper*: 3-100 mm
Taper Thread External (d2)*: up to 80 mm
Taper Thread Internal (D2)*: 3 -100 mm
Performance data
X axis resolution: 0.1 pm
Measurement uncertainty: 0.5+ L/1000 µm
Measuring force: 0.2 N
Work Table / Vertical Axls
Work table dimension: 150 X150 mm
Height adjustment: 60 mm
Resolution: 0.1pm
Load Capacity: 5 kg
Dimensions, weight and operational conditions
LxWxH: 600 x250 x470 mm
Weight (kg): 60 kg
Power supply: 230 VAC, 50 Hz
Display System: DRO
