NXP NCX2202GW,125 Analog Comparators Open Drain 1.3-5.5V

Shutdown: No Shutdown

Input Type: Rail-to-Rail

Output Type: Open Drain

Unit Weight: 5.335 mg

Response Time: 800 ns

Mounting Style: SMD/SMT

Comparator Type: General Purpose

Number of Channels: 1 Channel

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 1.3 V

Pd - Power Dissipation: 250 mW

Propagation Delay Time: 800 ns

Ib - Input Bias Current: 1 pA

Operating Supply Current: 6 uA

Vcm - Common Mode Voltage: 0 V to 5.5 V

Output Current per Channel: 68 mA

Vos - Input Offset Voltage: 3 mV

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

CMRR - Common Mode Rejection Ratio: 70 dB

PSRR - Power Supply Rejection Ratio: 80 dB
