Gain: 31.7 dB
Technology: InGaP
Unit Weight: 22 mg
Mounting Style: SMD/SMT
Test Frequency: 900 MHz
NF - Noise Figure: 4 dB
Operating Frequency: 400 MHz to 1 GHz
Supply Voltage - Max: 5 V
Supply Voltage - Min: 3 V
Operating Supply Current: 74 mA
Operating Supply Voltage: 3 V to 5 V
P1dB - Compression Point: 29.6 dBm
OIP3 - Third Order Intercept: 42 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
