NXP DSP56F807VF80E DSCs 16 BIT HYBRID CONTROLLER

Core: 56800

Width: 15 mm

Height: 1.18 mm

Length: 15 mm

Unit Weight: 585.800 mg

Data RAM Size: 4 kB

ADC Resolution: 12 bit

Data Bus Width: 16 bit

Interface Type: CAN, SCI, SPI

Mounting Style: SMD/SMT

Number of I/Os: 32 I/O

Number of Cores: 1 Core

Watchdog Timers: Watchdog Timer

Moisture Sensitive: Yes

Program Memory Size: 128 kB

Program Memory Type: Flash

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 3 V

Maximum Clock Frequency: 80 MHz

Operating Supply Voltage: 3.3 V

Number of Timers/Counters: 4 Timer

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
