NXP MK24FN1M0VDC12 MCU+DSP+FPUs K60-1M

Core: ARM Cortex M4

Unit Weight: 54 mg

Data RAM Size: 256 kB

Data RAM Type: SRAM

ADC Resolution: 16 bit

DAC Resolution: 12 bit

Data Bus Width: 32 bit

Interface Type: CAN, I2C, I2S, SPI, UART, USB

Mounting Style: SMD/SMT

Number of I/Os: 83 I/O

Development Kit: FRDM-K64F

Watchdog Timers: Watchdog Timer

Processor Series: K24

Program Memory Size: 1 MB

Program Memory Type: Flash

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 1.71 V

Analog Supply Voltage: 1.71 V to 3.6 V

Number of ADC Channels: 4 Channel

Maximum Clock Frequency: 120 MHz

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
