NOVOTEST TP-2020 Coating Thickness Gauge (0µm~60mm; PC connection)

Thickness measurement range(depends on probe type): 0 µm … 60 mm

Measured parameter: coating thickness, corrosion depth, roughness, temperature, humidity, dew point temperature

Measuring units: μm, mm, inch, mil

Revision modes: calculation of average, indication of minimum and maximum

PC connection: yes

Menu languages: English, Spanish, French, Russian

Dimensions, mm: 122x60x25

Operating temperature range, °C: -20 … +40°C

Batteries: 2 AA

Type of connectors of probes: Lemo

Storage of measurement results and PC software (optional): 256

Time of continuous work hours, not less: 20

Weight of electronic unit with batteries, no more, kg: 0.2

Standard package:

- Thickness gauge electronic unit TP-2020

-Standart probe ( by customer’s choice)

-Set of reference thickness samples

-Batteries (AA) – 2 pcs

-Charger

-USB cable

-Operating manual

-Case

Optional Probes:

- Probe F-0.3 – 0-300μm. Measurement of paint, varnish and galvanic coatings

-Probe F-0.5 – 0-500μm. Measurement of paint, varnish and galvanic coatings

-Probe F-2 – 0-2000μm. Measurement of paint and varnish coatings

-Probe F-5 – 0-5000μm. Measurement of paint, varnish and mastic coatings

-Probe NF-2 – 0-2000μm. Measurement of anodic-oxide films and paint coatings

-Probe M-12 – 0-12 mm. Measurement of mastic coatings

-Probe M-30 – 0-30 mm. Measurement of mastic coatings

-Probe M-60 – 0-60 mm. Measurement of mastic coatings

-Probe DSH-2-300 μm – Measurement of surface roughness after sand and shot blasting

- Probe DT– Temperature measurement

-Probe DTVR – Measurement of temperature, humidity and dew point

Description:

Coating thickness gauge NOVOTEST TP-2020 is designed for thickness measuring of coatings based on ferrous and non-ferrous metals. Variety of various sensors make it possible of non-destructive testing of protective coatings with a wide thicknesses range. Thickness gauge can also measure next parameters: the depth of grooves and corrosion, surface roughness as well as temperature control, ambient humidity and dewpoint temperature, therefore covering a wide range of tasks by one universal unit (thickness gauge).

Advantages:

- Measures coating thickness on ferrous (Fe) and non-ferrous (nFe) metals

- Automatic sensor detection

- Wide range of sensors for different tasks

- Selecting units of measure

- Storing individual calibrations in probes memory

- Average calculation, minimum and maximum indication

- High measurement accuracy

- Transfer of measurement data to PC via usb

- Portability

- Large buttons

- Enlarged screen

- Shockproof housing with a special protective silicone bumper case

- Charge control
