Taper: Linear
Width: 7 mm
Height: 5.8 mm
Length: 7 mm
Tolerance: 10 %
Adjustment: Top Crossed Slot
Resistance: 100 Ohms
Orientation: Vertical
Element Type: Cermet
Power Rating: 500 mW (1/2 W)
Mounting Style: PCB Mount
Voltage Rating: 7.07 VDC
Number of Turns: 1 Turn
Termination Style: PC Pin
Temperature Coefficient: 100 PPM / C
Maximum Operating Temperature: + 120 C
Minimum Operating Temperature: - 55 C
