Current: ±3A/CH
Voltage: 6V/CH
Power: 18W/CH
Channels: 24CH
CV Mode
Range: 0~6V
Setting Resolution: 0.1mV
Setting Accuracy（23±5℃): 0.6mV
Readback Resolution: 0.1mV
Readback Accuracy ( 23±5℃): 0.6mV
Temperature Coefficient（0~40℃): 20ppm/℃
Long-term Stability: 80ppm/1000h
Voltage Ripple Noise（20Hz-20MHz): ≤2mVrms
CC Mode
Range: -3~3A/ -1~1mA
Setting Resolution: 0.1mA/ 0.1μA
Setting Accuracy（23±5℃): 3mA/ 1μA
Readback Resolution: 0.1mA/0.1μA
Readback Accuracy ( 23±5℃): 3mA / 1μA
Temperature Coefficient（0~40℃): 30ppm/℃
Long-term Stability: 100ppm/1000h
Load Regulation: 0.01%+0.2mV
Isolation (Output to ground): 1500VDC
Isolation (Inter-channel): 500VDC
Communication Response Time: ≤10ms
Interface: LAN/RS232/CAN
AC Input: Single phase, 100~240V AC, current≤8A@220V,≤14A@110V, frequency 47Hz~63Hz
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 20kg
Dimension:
3U, 132.5(H)*482.0(W)with handle*559.0(D)mm
3U, 132.5(H)*482.0(W)with handle*718.0(D)mm with NB108-2
