Current: 2A/CH
Voltage: 5V/CH
Power: 10W/CH
Channels: 16CH
CC Mode
Range: 0~2A
Setting Resolution: 0.1mA
Setting Accuracy（23±5℃): 2mA
Readback Resolution: 0.1mA
Readback Accuracy ( 23±5℃): 2mA
Temperature Coefficient（0~40℃): 50ppm/℃
Long-term Stability: 100ppm/1000h
CV Mode
Range: 0~5V
Setting Resolution: 0.1mV
Setting Accuracy（23±5℃): 0.6mV
Readback Resolution: 0.1mV
Readback Accuracy ( 23±5℃): 0.6mV
Temperature Coefficient（0~40℃): 30ppm/℃
Long-term Stability: 100ppm/1000h
Voltage Ripple Noise（20Hz-20MHz): ≤2mVrms
Isolation (Output to ground): 1500VDC
Isolation (Inter-channel): 500VDC
Communication Response Time: 10ms
Interface: LAN/RS232
AC Input: Single phase, 220V AC±10%, current <5A, frequency 47Hz~63Hz
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 20kg
Dimension: 2U, 88(H)*482(W)*568.5(D)mm
